SSX-200 Part Catalog PDF

Petunjuk Pemakaian Catalog
Parts Catalog ini digunakan untuk memesan/mencari part dari kode VIAR pada kolom “Part Number“ di sebelah
pengganti, di dalamnya terdapat semua parts untuk type nomor part yang bersangkutan.
sepeda motor VIAR “New VIX R 200”.
Warna Part seperti ditunjukan pada table berikut ;
I. CARA MEMESAN PART STANDARISASI KODE WARNA
1. Informasi Yang Diperlukan WARNA KODE
Pemesan part pengganti sebaiknya mencantumkan Hitam BC
Part Number dan Nomor Seri seperti diterangkan di Merah RD
bawah. Hal ini diperlukan oleh karena setiap Biru BL
perubahan dan modifikasi pada parts telah didaftarkan Silver SV
di VIAR berikut nomor part dan nomor seri yang
Hijau GN
bersangkutan.
Coklat BR
2. Nomor-Nomor Yang Dibutuhkan : Gray GY
Parts mesin : Part Number dan Nomor seri mesin Tanpa Warna NC
Parts rangka : Part Number dan Nomor seri rangka Putih WH
Kuning YL
II. CARA MEMBACA PARTS KATALOG Orange OR
1. Susunan Nomor Part
(contoh) General Parts
STANDARISASI KODE KHUSUS WARNA STRIPE
WARNA KODE
Hitam 1
Merah 2
Biru 3
(contoh) Baut-baut, mur-mur dan standart part lain.
Hijau 4
Orange 5
Putih 6
Silver 7
2. Kode Warna Gray 8
Kode warna pada bagian belakang nomor part
menunjukan warna part tersebut. Kode BC, RD, BL, Contoh penulisan kode warna Stripe :
SV, GN, BR, dan seterusnya tidak secara langsung • Hitam-Merah : 12
menunjukan warna part, melainkan warna dapat dilihat • Merah-Hitam : 21
ii
3. Singkatan 5. Parts yang dipersatukan (Assemblies)
Dibawah ini adalah daftar singkatan-singkatan yang Part pada gambar yang dikelilingi dengan garis yang
digunakan di dalam Part Catalog sebagai berikut : terputus-putus tersedia sebagai parts yang
dipersatukan. Masing-masing komponen daripada
Assy. ……………………… Assembly
susunan parts itu dapat juga diperoleh secara terpisah.
Comp. ……………………. Complete
R. …………………………. Right
6. Jumlah yang diperlukan
L. ………………………….. Left
Angka di dalam kolom “QTY” menunjukan jumlah part
Std ………………………… Standard
tersebut yang dipakai dalam bagian yang
MM ……………………….. Millimeter
bersangkutan.
G ………………………….. Gram
T (17) …………………….. Teeth (17 Teeth)
7. Illustrasi
A ………………………….. Ampere
Nama parts tidak diterjemahkan kedalam bahasa
V ………………………….. Volt
Indonesia, melainkan tetap menggunakan istilah
W …………………………. Watt
resminya di dalam bahasa Inggris, agar seragam
L (100L) ………………….. Link (100 Links)
dengan istilah Internasional.
A.C ...……………………... Alternating Current
D.C ..……………………… Direct Current
IN. ………………………… Inlet
EX. ……………………….. Exhaust
FR. ……………………….. Front
RR. ………………………. Rear
HEX. ……………………... Hexagonal
C.D.I. …………………….. Capacitive Discharge
Ignition
4. Dimensi
Semua ukuran diberikan dalam satuan millimeter (mm)
kecuali untuk peluru baja (steel balls) ban luar (Tires)
dan ban dalam (Tire Tubes)
iii
iv
ENGINE GROUP
EV - 1 Cylinder Head EV - 2 Cam Shaft / Valve EV - 3 Cam Chain / Tensioner
EV - 4 Cylinder EV - 5 Right Crank Case Cover EV - 6 Clutch
EV - 7 Oil Pump EV - 8 Left Crank Case Cover EV - 9 Generator
v
ENGINE GROUP
EV - 10 Crank Case EV -11 Crankshaft / Piston EV -12 Transmission
EV -13 Gearshift Drum EV -14 Kick Starter Spindle EV -15 Starting Gear
EV -16 Starting Motor EV - 17 Carburetor EV - 18 Balance Shaft
vi
FRAME GROUP
F.V2R – 1 Head Light F.V2R – 2 Meter Assy F.V2R – 3 Handle Lever/Cable/ Mirror
F.V2R – 5 Handle Pipe /

F.V2R – 4 Front Brake Master Cylinder F.V2R – 6 Steering Stem
Top Bridge
F.V2R – 7 Front Fender F.V2R – 8 Front Fork F.V2R – 9 Front Wheel
vii
FRAME GROUP
F.V2R – 10 Rear Brake Master
F.V2R – 11 Rear Wheel F.V2R – 12 Fuel Tank
Cylinder
F.V2R – 13 Body Cover F.V2R – 14 Double Seat F.V2R – 15 Air Cleaner
F.V2R – 16 Exhaust Muffler F.V2R – 17 Pedal F.V2R – 18 Step
viii
FRAME GROUP
F.V2R – 19 Stand F.V2R – 20 Swing Arm / Chain Case F.V2R – 21 Rear Cushion
F.V2R – 22 Rear Fender F.V2R – 23 Caution F.V2R – 24 Taillight
F.V2R – 25 Battery F.V2R – 26 Wire Harness F.V2R – 27 Frame Body
ix
FRAME GROUP
F.V2R – 28 Tool Kit F.V2R – 29 Stripe F.V2R – 30 Oil Cooler
F.V2R – 31 Upper Cowl F.V2R – 32 Shroud and Cowl Cover
x
EV - 1
Cylinder Head
No Part Number Description Qty Notes No Part Number Description Qty Notes
1 94021-08000-00 Nut Cap M8 4 18 91000-75002-00 O-Ring 75×2.65 1 Not Used
2 90440-08502-02 Washer Sealing 8.5×2×18 4 18a 91000-75025-00 O-Ring 75×2.5 1
3 96000-06035-00 Bolt Flange M6×35 4 19 12339-V20-000 Gasket，L.Cover 1
4 16213-V20-000 Gasket, Insulator Carburetor, Aluminium 1 20 12331-V20-000-BC L. Cover，Cylinder Head 1
5 91000-35003-00 O-Ring 35×3 2 21 96000-06020-03 Bolt Flange M6×20 2 Diganti Part no 13
6 98069-S15-000 Spark Plug GP24 1 22 12251-V20-000 Gasket, Cylinder Head 1
7 94241-S15-000 Pin Dowel 8×14 2 23 12361-S15-000-BC Cap, Tappet Adjusting Hole*Black* 2
8 90033-08040-00 Bolt Stud M8×40 2 Not Used 12361-S15-000-SV Cap, Tappet Adjusting Hole*Silver* 2
8a 90033-08038-00 Bolt Stud M8×38 2 24 16211-V15-000 insulator Carburetor 1
9 12271-S15-000 Rubber, Oil Seal 1 25 16212-O15-000 Fiber, Insulator Carburetor, Aluminium 1
10 12001-V20-000-BC Cylinder Head Assy*Black* 1 26 12362-S15-000 Cap Assy., Tappet Adjusting Hoe 2
12001-V20-000-SV Cylinder Head Assy*Silver* 1 27 11344-V20-000 Clamp. Tube Breather 1
11 91304-S15-000 O-Ring 33.5×3.0 1
12 16215-V20-000 Pipe In Assy. (JQ-41) 1 Not Used
12a 16215-V15-000 Insulator, Carburetor Almunium assy 1
13 96000-06020-00 Bolt Flange M6×20 4
14 90033-06016-00 Bolt Stud M6x16 2
15 94001-06000-00 Nut Hex.,M6 2
16 96000-06119-03 Bolt Flange M6×119 1
17 94101-06000-00 Washer Plain 6 mm 1 Not Used
17a 94101-06000-03 Washer Plain 6 mm 1
Page 1
EV - 2
Cam Shaft / Valve
1 90206-S15-000 Adjusting Nut, Tappet 2
2 90012-S15-000 Adjusting Screw, Tappet 2
3 14430-S15-000 Rocker Arm Assy. 2 Not Used
3a 14431-V20-000 Rocker Arm Assy. New 2
4 14781-S15-000 Valve Cotter 4
5 14771-S15-000 Spring Seat, Valve 2
6 90000-63030-00 Bearing Radial Ball 6203 1
7 12208-V20-000 Seal, Valve Steam 2
8 14776-S15-000 Valve Spring Inner Seat 2
9 14775-S15-000 Valve Spring Outer Seat Valve 2
10 14711-V20-000 In Valve 1
11 14721-V20-000 Ex. Valve 1
12 14451-S15-000 Shaft, Valve Rocker Arm 2
13 14102-S15-000 Camshaft Comp., Single Bearing 1 Not Used
13a 14101-V20-000 Camshaft Comp., Double Bearing 1
14 14456-S15-000 Position Plate, Rocker Shaft 1
15 93600-06016-03 Screw Flate Pan M6×16 1
16 14751-S15-000 Spring Valve Outer 2
17 14761-S15-000 Spring Valve Inner 2
18 14762-S15-000 Inner Spring Set 2
Page 2
EV - 3
Cam Chain /
Tensioner
1 14321-S15-000 Timing Driven Sprocket cam 34T 1
2 14401-V20-000 Timing Chain (1002) 1
3 14500-V20-000 Tension Plate Assy. 1
4 14550-V20-000 Guide Plate Chain 1
5 14520-V20-000-BC Lifter Assy. 1
6 14523-S15-100 Gasket, Tensioner Lifter 1
7 14524-V20-000 Plate, Cam Chain Setting 1
8 14521-V20-000 Lifter Tensioner 1
9 96100-06012-00 Bolt Hex.,M6×12 3 Not Used
9a 96100-06012-03 Bolt Hex.,M6×12 3
10 14535-S15-000 Bolt, Cam Chain Tensioner Pivot 1
11 96700-06016-00 Bolt Socket M6×16 2 Not Used
11a 96700-06016-04 Bolt Socket M6×16 2
12 93501-06010-00 Screw Truss Head M6×10 1
13 91000-09001-00 O-Ring 9×1.8 1
14 90440-08500-02 Washer Sealing 8.5 1
Page 3
EV - 4
Cylinder Block
1 12101-V20-000-BC Cylinder Comp. (196 cc)*Black* 1
12101-V20-000-SV Cylinder Comp. (196 cc)*Silver* 1
2 94300-S15-000 Pin Dowel 10×20 2
3 12191-V20-000 Gasket Cylinder Block 1
Page 4
EV - 5
Right Crank Case
1 96000-06040-03 Bolt Flange M6×40 11
2 96000-06045-03 Bolt Flange M6×45 1
3 96800-V15-000 Sign glass 1
4 11333-V20-000 Cover Comp. Right Crankcase 1
5 22810-S15-000 Controling Arm , Clutch 1
6 94301-S15-000 Pin Dowel 8×14 2
7 94401-S15-100 Oil Seal, 12x22x5 1
8 22815-S15-000 Clutch Lever Spring 1 Not Used
8a 91201-S15-000 Spring, Clutch Lever 1
9 91200-16287-01 Oil Seal 16×28×7 1
10 94201-03016-00 Pin Split 3×16 1 Not Used
10a 94201-03010-00 Pin Split 3×10 1
11 15651-V20-000 Gauge, Oil Level Assy. 1
12 91000-18003-00 O-Ring 18×3 1
13 15650-V15-000-SV Gauge, Oil Level 1
14 11394-V20-000 Gasket R., Crankcase Cover 1
15 96000-06030-00 Bolt Flange M6x30 1
Page 5
EV - 6
Clutch
1 22368-V20-000 Shaft, Rod Clutch Lifter 1 1,2 assy 14
2 22366-V20-000 Rod Clutch Lifter 1
3 90050-S15-100 Bolt, Special Flange M5×20 6
5 22361-S15-100 Plate, Clutch Lifter ( 6 ) 1
6 94510-17000-00 Circlip Ex. 17 mm 1
7 95014-S15-100 Spring, Clutch 6
8 22123-S15-100 Center Comp., Clutch ( 6 ) 1
9 22312-S15-100 Plate, Clutch Friction, 1,8mm 6
10 22202-S15-100 Disc, Clutch 5 5
11 22351-S15-100 Plate Clutch Pressure ( 6 ) 1
12 22124-S15-000 Washer Spline, Clutch 1
13 22001-V15-100 Outer Comp., Clutch, 70T 1
14 22000-V15-000 Clutch Assy. 1 Not Used
14a 22000-V20-000 Clutch Assy. 69T 1
Page 6
EV - 7
Oil Pump
1 96000-06012-00 Bolt Flange M6×12 2 Not Used 19 15436-S15-000 Cap, Oil Filter Rotor 1
1a 96000-06012-03 Bolt Flange M6×12 2 20 15441-S15-000 Through, Oil 1
2 70001-V20-000 Oil Pump Gear Cover 1 21 93700-05012-00 Screw Pan Oval M5×12 3
3 70002-V20-000 Chain, Oil Pump 1 22 15446-S15-000 Spring, Oil Through 1
4 94050-06000-00 Nut Flange M6 1 Not Used 23 15459-S15-000 Gasket, Oil Filter Rotor Cap 1
4a 94050-06000-03 Nut Flange M6 1 24 15400-S15-000 Oil Filter Rotor Cap Assy. 1 17,16,15, 21 ikut assy.
5 70003-V20-000 Sprocket Oil Pump 23T 1
6 70004-V20-000 Sprocket-P 16T 1
7 96000-06032-03 Bolt Flange M6×32 2
8 70005-V20-000 Shaft Oil Pump 1
9 70006-V20-000 Oil Pump Body 1
10 70007-V20-000 Outer Rotor Oil Pump 1
11 70008-V20-000 Inner Rotor Oil Pump 1
12 70009-V20-000 Oil Pump Cover 1
13 93600-03008-00 Screw Flate M3×8 2
14 15101-V20-000 Oil Pump Assy. 1
15 15430-S15-000 Rotor Comp., Oil Filter 1
16 15451-S15-000 Washer Outside 1
17 90231-16000-01 Nut Lock M16 1
18 94251-80000-00 Pin, Lock, 8mm 1
Page 7
EV - 8
Left Crank Case
Cover
1 96000-06040-03 Bolt Flange M6×40 5
2 96000-06050-00 Bolt Flange M6×50 2
3 96000-06020-03 Bolt Flange M6×20 3 Not Used
3a 96000-06020-00 Bolt Flange M6×20 3
4 96000-06028-01 Bolt Flange M6×28 2
5 90703-S15-000 Pin Dowel 10×14 2
6 11395-V20-100 Gasket L Crankcase Cover 1
7 11341-V20-000-BC Cover, L. Crank Case (Black) 1
8 11355-V20-000-BC Cover, Reduction Gear (Black) 1
9 11342-V20-000-BC Back Cover L Crankcase (Black) 1
10 96000-06025-03 Bolt Flange M6×25 1
11 91000-13002-00 O-Ring 13.2×2.65 1
12 91305-S15-000 O-Ring 62×3 1
13 11343-V20-000 Collar Reduction Gear 1
14 90086-C10-000 Cap AC Generator 1
15 90089-C10-000 Cap 30 mm 1
16 91356-S15-100 O-ring 27x2,5 1
Page 8
EV - 9
Generator
1 31111-V20-000 Rotor Assy. 1
2 32975-V20-000 Stator Assy.AC ( 8 Pole ) 1 Not Used
2a 32975-V20-001 Stator Assy.DC (12 Pole) 1
3 96100-05016-00 Bolt Hex., M5×16 2
4 96100-05025-03 Bolt Hex., M5×25 3
5 96700-08018-03 Bolt Socket M8×18 3
6 31110-V20-000 Fly Wheel Comp. 1
7 31112-V20-000 Outer Comp., Starting Clutch 1
Page 9
EV- 10
Crank Case
1 96000-06055-03 Bolt Flange M6×55 1 18 11103-V20-000 Gearshift Swich Plate 1
2 22838-V20-000 Holder, Clutch Wire 1 19 11104-V20-000 Gearshift Switch Cable 1
3 11345-V20-000 Bolt Stud Special M10x222*Kecil* 1 20 93600-06020-00 Screw Flate Pan M6×20 1
4 90001-15120-00 Needle Bearing HK 1512 1 21 98070-V20-000 Clamp Cable Coil 1
5 90000-60060-00 Bearing Radial Ball 6006 1 22 96000-06012-00 Bolt Flange M6×12 1 Not Used
6 90001-21100-00 Needle Bearing HK2110 1 22a 96000-06012-03 Bolt Flange M6×12 1
7 90000-62040-00 Bearing Radial Ball 6204 1 23 96000-06050-00 Bolt Flange M6×50 11
8 11101-V20-000-BC Crankcase R. Comp.*Black* 1 Not Used 24 91200-20347-01 Oil Seal, 20×34×7 1
8a 11100-V20-000-SV Crankcase R. Comp.*Silver* 1 25 90001-62020-00 Bearing Radial 6202Z 1
9 94241-10014-00 Pin Dowel 10×14 4 26 90410-W20-000 Washer,drain plug 1
10 90033-10222-00 Bolt Stud M10x222*Besar* 1 27 15004-W20-000 Drain plug 1
11 11191-V20-000 Gasket Crankcase 1 28 15772-S15-000 Clip, Tube Breather 1
12 11200-V20-000-BC Crankcase L. Comp.*Black* 1 29 15761-S15-000 Tube Breater 1
11200-V20-000-SV Crankcase L. Comp.*Silver* 1 30 90033-10335-00 Bolt Stud M10x335 2
13 15421-S15-000 Screen, Oil Filter 1 31 11343-V20-000 Collar Shaft Reduction 1
14 15426-S15-000 Spring, Oil Filter Screen 1
15 91303-S15-100 O-Ring 35×3 1
16 12361-S15-000-BC Cap, Tappet Adjusting Hole *Black* 1
12361-S15-000-SV Cap, Tappet Adjusting Hole *Silver* 1
17 91200-14287-01 Oil Seal 14×28×7 1
Page 10
EV -11
Crankshaft / Piston
1 13013-V20-000 Ring Piston Set 1
2 94601-V20-000 Clip Pin Piston 2
3 13111-V20-000 Pin Piston 1
4 13104-V20-000 Piston Ø65 mm 1
5 90000-06028-00 Bearing, Radial Ball, 63-28(SC06B42) 2
6 13000-V20-000 Crank shaft Assy. 1
7 90701-S15-200 Semicircle Key 25×14×4 2
8 14311-V20-200 Sprocket, Timing Silent 17T 1
9 13202-V20-000 Crankshaft 1
10 96000-10036-00 Bolt Flange M10×36 1 Not Used
10a 96000-10036-01 Bolt Flange M10×36 1
11 13201-V20-000 Connecting Rod 1
Page 11
EV-12
Transmission
1 23211-V20-000 Main Shaft Transmission 1 21 23451-V20-000 Gear, Counter Shaft Second 28T 1
2 23441-V20-000 Gear, Main Shaft Second 15T 1 22 90454-S15-000 Washer, Thrust, 20mm 1
3 23501-V20-000 Gear, Main Shaft Fifth 22T 1 23 90452-S15-000 Washer, Thrust, 15mm 1
4 90455-S15-000 Washer A, Spline, 20mm 3 24 23531-S15-000 Gear Only, Idle Starter 29T 1
5 90605-S15-000 Circlip Ex. 20mm 3 25 23801-V15-000 Sprocket Drive 15T 1
6 23481-V20-000 Gear, Main Shaft Fourth 20T 1 26 23811-S15-000 Plate Fixing 1
7 23461-V20-000 Gear, Main Shaft Third 18T 1 27 96100-06010-00 Bolt Hex M6×10 2 Not Used
8 23221-V20-000 Main Shaft, Transmission 11T 3 27a 96100-06010-03 Bolt Hex M6×10 2
9 90453-S15-000 Washer, Thrust, 20mm 1
10 23520-V20-000 Gear Comp., Starter 19T 1
11 23212-V20-000 Collar Bush Sub Axle Starting Gear 1
12 90451-V20-000 Washer, Thrust, 15mm 1
13 23220-V20-000 Counter Shaft Transmission 1
14 23427-V20-000 Collar, Counter Shaft Low Gear 1
15 90452-S15-000 Washer A, Thrust, 16.5mm 2
16 23426-V20-000 Gear, Counter Shaft 32T 1
17 23471-V20-000 Gear, Counter Shaft Third 25T 1
18 23491-V20-000 Gear, Counter Shaft Fourth 23T 1
19 23221-V20-000 Counter Shaft, Transmission 1
20 23511-V20-000 Gear, Counter Shaft Fifth 21T 1
Page 12
EV-13
Gearshift Drum
1 96100-06020-00 Bolt Hex., M6×20 1 Not Used 19 94510-14000-00 Circlip, External, 14mm 1
1a 96100-06020-03 Bolt Hex., M6×20 1 20 94510-12000-00 Circlip, External, 12mm 1
2 24430-S15-000 Stopper Comp., Gear Shift Drum 1
3 24435-S15-000 Spring, Shift Drum Stopper 1
4 96100-06025-00 Bolt, Hex.,6x25 1
5 94111-06000-00 Washer Spring 6 mm 1 Not Used
5a 94111-06000-03 Washer Spring 6 mm 1
6 24411-S15-000 Cam, Gearshift 1
7 96220-S15-000 Roller, 4x10 1
8 24301-V20-000 Drum, Gearshift 1
9 24241-S15-000 Shaft, Gearshift Fork Guide 1
10 24211-V20-000 Fork R Gear Shift 1
11 24231-V20-000 Fork Center Gear Shift 1
12 24221-V20-000 Fork L Gear Shift 1
13 24200-V20-000 Gearshift Spindle Comp. Assy. 1
14 24631-V20-000 Spring, Gearshift Plate 1
15 24621-V20-000 Plate, Gearshift 1
16 24610-V20-000 Spindle comp., Gearshift 1
17 24651-V20-000 Spring, Gearshift Return 1
18 90451-V20-000 Washer, Thrust, 16mm 2
Page 13
EV -14
Kick Starter Spindle
1 28250-V20-000 Kick Starter Spindle Assy. 1
2 90410-12000-00 Washer, Plate. 12mm 1
3 94510-16000-00 Circlip, External, 16mm 1
4 28255-V20-000 Guide Plate Assy. 1
5 28253-S15-000 Spring, Kick Starter Ratchet 1
6 90456-V20-000 Washer A, Thrust 16x24 mm 1
7 28221-V20-000 Ratchet, Kick Starter 1
8 94510-20000-00 Circlip, External, 20mm 1
9 90453-V20-000 Washer A, Thrust, 20mm 1
10 28211-V20-000 Pinion, Kick Starter 29T 1
11 28251-V20-000 Spindle, Kick Starter 1
12 28263-V20-000 Retainer, Starting Spring 1
13 28261-V20-000 Spring, Kick Starter 1
14 28262-V20-000 Collar, Kick Spindle 1
15 9045-V20-000 Washer A, Thrust 16x30mm 1
Page 14
EV -15
Starting Gear
1 28143-S15-000 Washer, Thrust, 10mm 4
2 28132-S15-000 Shaft, Reduction 1
3 28134-V20-000 Gear, Reduction Assy. 17/60T 1
4 28133-V20-000 Idle Gear 17/16T 1
5 28110-V20-000 Gear Comp., Starting Driven 57T 1
6 28135-V20-000 Washer Wave 22×6.0×34 1 Not Used
7 28136-V20-000 Washer Wave 22×3.5×34 1 Not Used
8 28130-V20-000 Gear, Reduction 60T 1
9 28135-X20-000 Washer Wave 22×9.25×33.2 1
Page 15
EV -16
Starting Motor
1 31200-V20-000-BC Motor Assy., Starting*Hitam* 1 21 90402-06000-00 Washer, 6mm 1
2 31201-S15-000 Holder, Set Brush 1 22 31213-S15-000 Bush, 10x16x12 1
3 31202-S15-000 Terminal, Set Brush 1 23 90605-S15-000 Circlip 1
4 31204-S15-000 Spring, Carbon Brush 2 24 90401-14000-00 Washer, 14mm 1
5 31205-S15-000 Bolt, Setting 2 25 31215-S15-000 Seal, 13.6x24x6 1
6 31207-S15-000 O-Ring, 60x1.5 2 26 90406-S15-000 Washer, Lock 1
7 32410-S15-000 Cable, Starter Motor 1 27 31216-S15-000 Collar, Case C 2
8 32411-S15-000 Cover, Motor Starter Terminal 1
9 90071-06000-00 Nut-Washer, 6mm 2
10 91322-24403-00 O-Ring, 24.4x3 1
11 91320-S15-000 O-Ring, 7.5x1.3 2
12 91321-S15-000 O-Ring, 13.6x2 1
13 96000-06028-00 Bolt, Flange, 6x28 (Kepala M10) 2
14 31208-S15-000 Case A, Fr. 1
15 31209-V20-000-BC Case B, Middle*Hitam* 1
16 31210-V20-000-BC Case C, Rr. *Hitam* 1
17 31211-S15-000 Current, Starting Motor 1
18 94111-06000-00 Washer, Spring, 6mm 1
19 90401-06000-00 Washer, 6mm 1
20 31212-S15-000 Collar, Ebonit, 6mm 1
Page 16
EV - 17
Carburetor
1 16010-S15-000 Gasket, seal 1 21 16165-S15-000 Holder, needle jet 1
2 16012-S15-000 Needle set, jet 1 22 16196-S15-000 Tube, 3.5x460 1
3 16013-S15-000 Float set 1 23 93301-04012-00 Screw-washer, 4x12 4
4 16014-S15-000 Top set 1 24 93301-04016-00 Screw-washer, 4x16 3
5 16015-S15-000 Chamber set, float 1 25 93301-05012-00 Screw-washer, 5x12 1
6 16016-S15-000 Screw set a 1 26 93301-05014-00 Screw-washer, 5x14 1
7 16018-S15-000 Arm set, pump 1 27 95002-S15-000 Clip, tube 1
8 16021-S15-000 Diaphragm set, pump 1 28 99110-S15-000 Jet, main #105 1
9 16022-S15-000 Valve set, throttle 1 29 99103-S15-000 Jet, slow 1
10 16025-S15-000 Lever set, chooke 1 30 16197-S15-000 Float Chamber 1
11 16028-S15-000 Screw set b 1
12 16031-S15-000 Arm set, pump 1
13 16076-S15-000 O-ring, 2.4x29 1
14 16075-S15-000 O-ring, 1.3x4.3 1
15 16100-V20-000 Carburetor assy. 1
16 16118-S15-000 Plate, stay 1
17 16119-S15-000 Plate, stay chooke 1
18 16148-S15-000 Cap, cable sealing 1
19 16155-S15-000 Valve comp., float 1
20 16163-S15-000 Gasket, float chamber 1
Page 17
EV - 18
Balance Shaft
1 18001-V20-000 Balance Shaft 1
2 18007-V20-000 Washer Thrust 16.2×2.7×22.5 1
3 23121-V20-000 Primary Gear 21T 1
6 18004-V20-000 Semicircular Key 25x14x4 1
7 90231-16000-00 Nut Lock M16 1
8 18005-V20-000 Driven Gear Balance 43T 1
9 18006-V20-000 Driven Gear Balance Crankshaft 43T 1
10 18008-V20-000 Driven Gear Balance Assy. 1
Page 18
F.V2R – 1
Head Light
1 10001-V2R-000 Headlight Assy. 1
2 10002-V2R-000 Headlight Unit Comp. 1
3 10003-V2R-000 Bulb 35/35W 12V 1
4 10004-V2R-000 Rubber Cover Head Lamp. 1
5 10005-V2R-000 Led 8
6 10006-V2R-000 Bulb 5W 12V 2
7 10007-V2R-000 Socket Comp. Head Lamp. 1
8 90044-04200-00 Screw Clip M4,2 2
9 90101-04213-00 Screw Tapping M4,2x13 4
10 10008-V2R-000 Fr. Winker R Assy. 1
11 10009-V2R-000 Fr. Winker L Assy. 1
12 10010-V2R-000 Led Cable Comp. R 1
13 10011-V2R-000 Led Cable Comp. L 1
14 30007-TVX-000 Led 20
15 10012-V2R-000 Fr. Base R/L Winker Assy. 2
16 94050-10000-00 Nut Plange M10 2
17 90101-04813-00 Screw Tapping M4,8x13 2
Page 19
F.V2R– 2
Meter Assy
1 20001-V2R-000 Meter Assy., Combination 1
2 20002-V2R-000 Case Meter Upper 1
3 20003-V2R-000 Gasket Meter 1
4 20004-V2R-000 Meter Combination 1
5 20005-V2R-000 Case Meter Lower 1
6 20006-V2R-000 Cap Meter 1
7 90101-03016-00 Screw Tapping M3x16 3
8 90101-04810-00 Screw Tapping M4,8x10 3
Page 20
F.V2R – 3
Handle Lever /
Cable / Mirror
1 30001-VIR-000 Cable Comp., Choke 1 21 88222-VIR-000 Mirror Set R/L 1
2 30002-VIR-000 Cable Comp., Clutch 1 22 88221-VIR-000 Mirror L 1
3 30003-V2R-000 Cable Comp., Throttle "TPFC" 1 23 88211-VIR-000 Mirror R 1
4 30004-V2R-000 Grip, L. Handle 1 24 30011-V2R-000 Lever Assy Clutch L Handle 1
5 30005-V2R-000 Grip, R. Handle "Throttle" 1 25 96700-06020-04 Bolt Socket M6x20 4
6 30006-V2R-000 Switch Assy., L Winker 1
7 30007-V2R-000 Switch Assy.,R Lighting Kill 1
8 93500-05040-01 Screw Pan M5x40 1
9 93500-05032-01 Screw Pan M5x32 1
10 93500-05018-01 Screw Pan M5x18 1
11 93500-05022-01 Screw Pan M5x22 1
12 53178-VIR-000 Lever Comp., Clutch L. Handle 1
13 53172-VIR-000 Bracket Clutch, Handle Lever 1
14 53172-VIR-000 Bracket, Handle Lever 1
15 96000-06028-01 Bolt, Flange, 6x28 2
16 90113-VIR-000 Screw Special, L. Lever Clutch M5x22 1
17 35330-VIR-000 Switch Comp., Fr Lever 1
18 53192-VIR-000 Bolt, Clutch Wire Adjusting 1
19 90321-VIR-000 Nut, Fixing 1
20 94001-05000-00 Nut Hex., 5mm 1
Page 21
F.V2R – 4
Front Brake
Master Cylinder
1 35340-VIR-000 Switch Assy., Fr. Stop 1 22 06451-VIR-000 Seal Set, Piston 4
2 45126-VIR-000 Hose Comp., Fr. Brake 1 23 06455-VIR-000 Pad Set, Fr. 1
3 94606-VIR-000 Lock Plate Fr. Brake 1 24 43352-VIR-000 Screw, Bleeder 1
4 45504-VIR-000 Boot Comp. 1 25 43353-VIR-000 Cap, Bleeder 1
5 90145-VIR-000 Spring Cylinder 1 26 45107-VIR-000 Piston 2
6 45510-VIR-000 Cylinder Sub Assy., Fr. Brake Master 1 27 45108-VIR-000 Spring, Pad 1
7 94607-VIR-000 Bracket Wire Clip 1 28 45111-VIR-000 Seal, Stopper 1
8 45513-VIR-000 Cap Master Cylinder 1 29 45131-VIR-000 Bolt, Pin 1
9 45517-VIR-000 Holder Master Cylinder 1 30 45132-VIR-000 Boot, Pin Bush 2
10 45520-VIR-000 Diaphragm 1 31 45133-VIR-000 Boot B 1
11 45521-VIR-000 Plate, Diaphragm 1 32 45215-VIR-000 Pin, Hanger 1
12 45530-VIR-000 Cylinder Set, Master 1 33 45216-VIR-000 Washer, Wave 2
13 53175-VIR-000 Lever, R. Steering Handle 1 34 45250-VIR-000 Caliper Sub Assy., R. Fr. 1
14 90114-VIR-000 Bolt, Handle Lever Pivot 1 35 45290-VIR-000 Bracket Sub Assy., R. Fr. 1
15 90145-VIR-000 Bolt, Oil , 10x22 2 36 96000-08032-01 Bolt, Flange, 8X32 2
16 90545-VIR-000 Washer, Oil Bolt 4 37 45291-VIR-000 Assy Front Brake M. Cylinder & Caliper 1
17 90605-VIR-000 Circlip 1 38 96000-06012-01 Bolt Flange M6x12 1
18 93600-04012-01 Screw, Flat, 4x12 2 39 45127-VIR-000 Clamp. Tube Fr. Brake 1
19 93301-04012-01 Screw with Washer, 4x12 1 40 96100-08035-01 Bolt Hex., M8x35 2 Not Used
20 90301-06000-00 Nut U, M6 1 41 96100-08032-04 Bolt Hex., M8x32 2
21 96000-06022-01 Bolt, Flange, 6x22 2
Page 22
F.V2R– 5
Handle Pipe /
Top Bridge
1 53106-VIR-000 Weight A, Steering Handle 2 21 96000-08035-00 Bolt Flange M8x35 2
2 54100-V2R-000 Key Set 1 22 54108-V2R-000 Rubber Body 2
3 35100-VIR-000 Switch Assy., Combination & Lock 1 23 54109-V2R-000 Rubber Light 2
4 54101-V2R-000 Safety Key Set 1 24 96000-06012-00 Bolt Flange M6x12 2
5 35120-VIR-000 Key, Blank 1
6 54102-V2R-000 Handle R, Steering 1
7 53104-VIR-000 Weight B, Handle 2
8 53103-VIR-000 Weight Steering Handle R/L Assy. 2
9 53105-VIR-000 Rubber B, Handle Weight 4
10 53107-VIR-000 Ring, Handle Weight Snap 2
11 54103-V2R-000 Handle L, Steering 1
12 54104-V2R-000 Bridge, Fork Top 1
13 54105-V2R-000 Cover Key Set 1
14 54106-V2R-000 Bracket front Top assy. 1
15 54107-V2R-000 Bracket front Top 1
16 93600-06060-00 Screw Flat, 6x60 2
17 94021-20000-03 Nut Cap M20 1
18 90503-VIX-000 Washer, Steering Stem 1
19 96000-06016-00 Bolt Flange6x16 2
20 96700-08035-03 Bolt Socket, 8x35 2
Page 23
F.V2R – 6
Steering Steam
1 53223-VIR-000 Steering Steam Assy. 1
2 53222-VIR-000 Steem Comp Steering 1
3 96100-10040-00 Bolt Hex., M10x40 2
4 94111-10000-00 Washer Spring 10 mm 2
5 90410-10000-00 Washer Plate 10 mm 2
6 53229-VIR-000 Rubber Washer Steerin Steam 1
7 53227-VIR-000 Washer Steering Steam Lower 1
8 90001-32024-00 Bearing Needle 320/24 1
9 53228-VIR-000 Race Steering 2
10 90001-32022-00 Bearing Needle 320/22,5 1
11 50306-VIR-000 Nut Lock M21 Steering Steam 1
Page 24
F.V2R – 7
Front Fender
1 70001-V2R-000-RD Front Fender*Merah* 1
70001-V2R-000-WH Front Fender*Putih* 1
70001-V2R-000-GN Front Fender*Hijau* 1
2 70002-V2R-000 Stay, Fr. Fender 1
3 70003-V2R-000 Bracket Fr. Fender L 1
4 70004-V2R-000 Bracket Fr. Fender R 1
5 96000-08012-00 Bolt Flange M8x12 6
6 93501-06012-01 Screw Truss Head M6x12 4 Not Used
7 90410-06000-01 Washer Plate 6 mm 4
8 70005-V2R-000 Stay Speedo Cable 1
9 73034-V2R-000 Screw Truss Head Special M6x12 4
Page 25
F.V2R– 8
Front Fork
1 51400-VIR-000 Fork Assy. R. Fr. 1
2 51500-VIR-000 Fork Assy, L Fr. 1
3 51420-VIR-000 Case R Fr Bottom 1
4 51520-VIR-000 Case L Fr Bottom 1
5 51432-VIR-000 Piece Oil Lock 2
6 51470-VIR-000 Pipe Seat 2
7 51425-VIR-000 Dust Seal 2
8 51466-VIR-000 Ring Oil Seal Stopper 2
9 51490-VIR-000 Seal Set Fr Fork 2
10 51401-VIR-000 Spring Fr Fork 2
11 51437-VIR-000 Ring, Piston 2
12 51454-VIR-000 Set B Spring 2
13 91356-VIR-000 O-Ring 2
14 94605-VIR-000 Bolt Fr Fork 2
Page 26
F.V2R – 9
Front Wheel
1 90001-V2R-000 Axle Front Wheel M12X215 1
2 42722-VIR-000 Cap Dop Tubeless Fr 1
3 42723-V2R-000 Dop Tubeless Fr 1
4 44311-VIR-000 Collar, Fr. Wheel Side 1
5 44620-VIR-000 Collar Fr. Axle Distance 1
6 44650-VIR-000 Wheel Sub Assy Fr. 1
7 90002-V2R-000 Gear Spedometer Digital Assy. 1
8 22517-V2R-100 Tire Fr. Tubeless (100/80-17) 1
9 90003-V2R-000 Indicator Signal Gear Speedo 1
10 90004-V2R-000 Gear Spedometer Digital 1
11 45251-VIR-000 Disc Fr Brake 1
12 96000-06020-01 Bolt Flange 6x20 5
13 90301-12000-00 Nut U M12 1
14 91252-VIR-000 Dust Seal 23x37x11 1
Page 27
F.V2R – 10
Rear Brake Master
Cylinder
1 43150-VIR-000 Caliper Assy. Rr Brake 1 21 45221-VIR-000 Tube Reserve Oil Brake 1
2 96451-VIR-000 Seal Set Piston 1 22 93501-06020-01 Screw Truss Head M6x20 1
3 43107-VIR-000 Piston 1 23 45223-VIR-000 Tube RearBrake 1
4 96465-VIR-000 PAD Set Rr 1 24 45224-VIR-000 Clamp. Tube Rear Brake 1
5 43190-VIR-000 Braket Assy Rr. Caliper 1 25 45225-VIR-000 Pump Oil Rear Brake 1
6 43215-VIR-000 Pin Hanger 1 26 45226-VIR-000 Spring A 1
7 43352-VIR-000 Screw Bleeder 1 27 45227-VIR-000 Spring B 1
8 43353-VIR-000 Cap Bleeder 1 28 96000-06016-01 Bolt Flange M6x16 1
9 45108-VIR-000 Spring Plate PAD 1 29 96000-06022-01 Bolt Flange M6x22 2
10 45111-VIR-000 Seal Stopper 1 30 94050-06000-00 Nut Flange M6 1
11 45131-VIR-000 Bolt Pin 1 31 93501-05012-01 Screw Truss Head M5x12 1
12 45132-VIR-000 Boot pin Bush 1
13 45133-VIR-000 Boot B 1
14 45203-VIR-000 Plug Pin 1
15 45216-VIR-000 Washer Wave 1
16 45217-VIR-000 Rear Brake Absorber ( ABS ) 1
17 45218-VIR-000 Lock Plate Rr. Brake 1
18 96100-08020-01 Bolt Hex., M8x20 2
19 45219-VIR-000 Reserve Oil Rear Brake 1
20 45220-VIR-000 ClipTube 2
Page 28
F.V2R – 11
Rear Wheel
1 16410-VIR-000 Damper Set Wheel 1 21 94001-08000-00 Nut Hex., M8 4
2 41200-VIR-000 Sproket Comp Final Driven (41T) 1 22 90000-62030-00 Bearing Radial Ball 6203 1
3 42301-VIR-000 Axle RR Wheel M14x300 1 23 90000-63010-00 Bearing Radial Ball 6202 2
4 42303-VIR-000 Sleeve RR Wheel 1
5 42312-VIR-000 Collar, L Rr. Wheel Side 15x26x26 1
6 42620-VIR-000 Collar, R Rr. Wheel Side15x35x14 1
7 42615-VIR-000 Flange Sub. Assy. Driven 1
8 42620-VIR-000 Collar Rr. Axle Distance 1
9 42601-VIR-000 Wheel Rr. Sub. Assy. 1
10 42752-VIR-000 Lock Plate Final Driven 2
11 42712-VIR-000 Cap Dop Tubeless 1
12 42711-V2R-000 Tire Rr. Tubeless (120/70-17) 1
13 42723-V2R-000 Dop Tubeless 1
14 43351-VIR-000 DiscRr. Brake 1
15 90105-VIR-000 Bolt Socket Special M8x25 4
16 96100-08042-00 Bolt Hex., M8x42 4
17 90301-14000-00 Nut U M14 1
18
19 42724-VIR-000 Oil Seal 23x37x11 1
20 91251-VIR-000 Dust Seal 26x40x6.5 1
Page 29
F.V2R – 12
Fuel Tank
1 12009-V2R-000 Bolt Flange Special Tank 8x98xM6x10 1 16 94050-06000-00 Nut Flange M6 4
2 12002-V2R-000-BC Fuel Tank comp.*Hitam* 1 17 91306-VIR-000 Clip Tube 2
12002-V2R-000-RD Fuel Tank Comp Merah 1 18 93510-VIX-000 O-Ring 39.5x5 1
12002-V2R-000-GN Fuel Tank Comp Hijau 1 19 93501-06012-01 Screw Truss Head M6x12 2
3 12003-V2R-000 Cap Comp Fuel Filler 1 20 96000-08025-00 Bolt Flange M8x25 1
4 12004-V2R-000 Bracket Fr. Fuel Tank 1 21 16961-KRY-000 Tube Of Water Pipe Ø 3/8 1
5 37800-V2R-000 Fuel Sensor Assy. 1
6 16950-VIR-000 Cock Assy Fuel Auto 1
7 16958-VIR-000 O-Ring 1
8 16952-VIR-000 Screen Set Fuel Strainer 1
9 17630-VIR-000 Tube Fuel 1
10 12005-V2R-000 Shroud Fr Fuel Tank 1
12005-V2R-000-BC Shroud Fr Fuel Tank Hitam 1
12005-V2R-000-RD Shroud Fr Fuel Tank Merah 1
12005-V2R-000-GN Shroud Fr Fuel Tank Hijau 1
11 12006-V2R-000 Rubber Support Fr. Tank 1
12 12007-V2R-000 Washer Collar 8x22x10 1
13 96000-06016-00 Bolt Flange M6x16 2
14 17612-VIR-000 Rubber Gromet Oval 6
15 12008-V2R-000 Rubber Rear Fuel Tank 2
Page 30
F.V2R – 13
Body Cover
1 13001-V2R-000 Cover Side R 1 15 90044-04217-00 Screw Clip M4,2x17 2
2 13002-V2R-000 Cover Side L 1 16 93501-05016-01 Screw Truss Head M5x16 2
3 13003-V2R-000-RD Cover Body Side R *Merah* 1 17 90101-04213-00 Screw Tapping 4,2x13 4
13003-V2R-000-WH Cover Body Side R *Putih* 1 18 93501-06016-00 Screw Truss Head M6x16 2
13003-V2R-000-GN Cover Body Side R *Hijau* 1 19 90044-04215-00 Screw Clip M4,2x15 2
4 13004-V2R-000-RD Cover Body side L *Merah* 1 20 31013-V2R-000 Clip Snap 2
13004-V2R-000-WH Cover Body side L *Putih* 1
13004-V2R-000-GN Cover Body side L *Hijau* 1
5 13005-V2R-000 Cowl Body R 1
13005-V2R-000-WH Cowl Body R"Putih" 1
6 13006-V2R-000 Cowl Body L 1
13006-V2R-000-WH Cowl Body L"Putih" 1
7 13007-V2R-000 Upper Taillight Cover 1
8 13008-V2R-000 Lower Taillight Cover 1
9 96000-06012-00 Bolt Flange M6x12 2
10 13010-V2R-000 Rubber Body Cover 4
11 17612-VIR-000 GrometOval 2
12 96000-06016-00 Bolt Flange M6x16 4
14 90101-04810-00 Screw Tapping M4,8x10 10
Page 31
F.V2R – 14
Double Seat
1 14001-V2R-000 Fr. Seat Comp. 1
2 14002-V2R-000 Fr. Seat 1
3 14003-V2R-000 Damper Seat A 8
4 14004-V2R-000 Damper Seat B 2
5 14005-V2R-000 Damper Seat C 2
6 96000-06016-00 Bolt Flange M6x16 2
7 96000-06025-00 Bolt Flange M6x25 2
10 14009-V2R-000 Rr. Seat Comp. 1
11 14006-V2R-000 Rr. Seat 1
12 14008-V2R-000 Rear Grip Right 1
13 14007-V2R-000 Rear Grip Left 1
14 96000-08020-00 Bolt Flange M8x20 4
15 14010-V2R-000 Bracket Comp.Seat Lock 1
16 14011-V2R-000 Cable Seat Lock 1
17 14012-V2R-000 Bracket Seat Lock 1
18 94050-06000-00 Nut Flange M6 2
19 14013-V2R-000 Spring Seat Lock 1
Page 32
F.V2R – 15
Air Cleaner
1 17252-VIR-000 Air Cleaner Assy. 1
2 17210-VIR-000 Filter 1
3 17213-VIR-000 Band Air Cleaning Connecting tube 1
4 17250-VIR-000 Case Sub Air Cleaner Assy 1
5 90101-05016-00 Screw Tapping 5x16 6
6 17235-VIR-000 Cover Sub air Cleaner 1
7 17214-VIR-000 Plate Filter 1
8 15001-V2R-000 Bolt Special Flange M6x17 2
Page 33
F.V2R – 16
Exhaust Muffler
1 16001-V2R-000 Muffler Assy. 1
2 16002-V2R-000 Muffler 1
3 16003-V2R-000 Rear Separator Cover 1
4 16004-V2R-000 Front Separator Cover 1
5 16005-V2R-000 Exhaust Bracket 1
6 93501-06010-00 Screw Truss Head M6x10 3
7 93500-06012-00 Screw Pan M6x12 2
8 94111-06000-00 Washer Spring M6 2
9 94101-06000-00 Washer Plain M6 2
10 96000-08035-00 Bolt Flange M8x35 1
12 90410-08000-00 Washer Plate M8 1
13 90301-08000-00 Nut U M8 1
14 96000-08055-00 Bolt Flange M8x55 1
15 16006-V2R-000 Rubber Stay Muffler 2
16 94021-08000-03 Nut Cap M8 2
Page 34
F.V2R – 16a
Exhaust Muffler (Seri e 2)
1 16101-V2R-000 Exhaust Muffler Assy. 1 21 16110-V2R-000 Separator Cover B 1
2 16102-V2R-000 Exhaust Muffler 1 22 96000-08035-01 Bolt Flange M8x35 1
3 16103-V2R-000 Separator Muffler Assy. 1 23 16111-V2R-000 Rubber Clamp Separotor 1
4 16104-V2R-000 Separator Muffler 1
5 18292-KRY-000 Gasket Ex. Pipe 1
6 16105-V2R-000 Gasket Muffler 1
7 93500-06014-03 Screw Pan M6x12 4
8 94111-06000-01 Washer Spring 6 mm 4
9 94101-06000-00 Washer Plain 6 mm 4
10 96000-08035-00 Bolt Flange M8x35 1
12 90410-08000-00 Washer Plate M8 1
13 90301-08000-00 Nut U M8 1
14 96000-08055-00 Bolt Flange M8x55 1
16 94021-08000-03 Nut Cap M8 2
17 16106-V2R-000 Ring Gasket 6 mm 4
18 16107-V2R-000 Clamp Exhaust Muffler 1
19 16108-V2R-000 Clamp Separator Muffler 1
20 16109-V2R-000 Separator Cover A 1
Page 34a
F.V2R – 16b
Exhaust Muffler (Seri e 3)
1 16201-V2R-000 Exhaust Muffler Assy. 1
2 16202-V2R-000 Exhaust Muffler 1
3 18355-VIR-000 Protector 1
4 16204-V2R-000 Separator Muffler 1
5 18392-KRY-000 Gasket Ex. Pipe 1
6 16205-V2R-000 Gasket Muffler Separator 1
7 93500-06014-01 Screw Pan M6x12 3
8 94111-06000-01 Washer Spring 6 mm 5
9 94101-06000-01 Washer Plain 6 mm 5
10 96000-08035-00 Bolt Flange M8x35 1
12 90410-08000-00 Washer Plate M8 1
13 90301-08000-00 Nut U M8 1
14 96000-08055-00 Bolt Flange M8x55 1
16 94021-08000-03 Nut Cap M8 2
17 96700-06025-01 Bolt Socket M6x25 3
18 18312-VIR-000 Guard Muffler 1
19 16108-V2R-000 Clamp Separator Muffler 1
20 16111-V2R-000 Rubber Clamp Separotor 1
Page 34b
F.V2R – 17
Pedal
1 94101-15000-01 Washer Plain 15 mm 1 21 24700-VIR-000 Pedal Gear Change Assy. 1
2 24701-VIR-000 Pedal Gear Change 1 22 96100-06020-00 Bolt Hex., M6x20 1
3 94101-14000-03 Washer Plain 14 mm 1 23 94001-06000-00 Nut Hex., M6 2
4 24711-VIR-000 Arm Gear Change 1 24 28301-VIR-000 Gag Lever Post 1
5 24720-VIR-000 Rod Tie 1 25 24723-VIR-000 Rubber Cap Kick Stater 1
6 24721-VIR-000 Cover Change Pedal Rr 1 26 24724-VIR-000 Bolt With Waser Plate & Spring M8x20 4
7 24722-VIR-000 Cover Change Pedal Fr 1
8 24781-VIR-000 Rubber Gear Change Pedal 1
9 35350-VIX-000 Switch Rr Stop 1
10 35357-VIR-000 Spring Stop Switch 1
11 46510-VIR-000 Pedal Brake 1
12 46513-VIR-000 Spring Pedal Brake 1
13 28300-VIR-000 Kick Starter Assy. 1
14 28311-VIR-000 Rubber Kick Starter 1
15 15773-VIR-000 Clip Swicth Rear Stop 1
16 94510-14000-01 Circlip Ex. 14mm 2
17 94201-02025-00 Pin Split 2x25 1
18 28333-VIR-000 Spring Kick Starter 1
19 28241-VIR-000 Joint Kick Arm 1
20 96100-08027-00 Bolt Hex., 8x27 1
Page 35
F.V2R – 18
Step
1 50610-VIR-000 Holder R Step 1 21 50717-VIR-000 Holder Fr. Pillion Step L Assy. 1
2 50639-VIR-000 Pin Step Bar Join Rear 2 22 94101-08000-00 Washer Plain 8mm 2
3 50640-VIR-000 Pin Step Bar Join Front 2 23 94201-01202-00 Pin Split 1.2x2.0 2
4 50635-VIR-000 Bar Comp R Step Fr 1 24 94201-01202-00 Pin Split 1.2x2.0 2
5 50712-VIR-000 Washer Pillion Step Fr. 2 25 50719-VIR-000 Holder Rr. Pillion Step L Assy. 1
6 50618-VIR-000 Sub Assy. Rr. Pillion Step L 1 26 50718-VIR-000 Holder Rr. Pillion Step R Assy. 1
7 50636-VIR-000 Sub Assy. Fr. Pillion Step R 1
8 50645-VIR-000 Bar Comp L Step Fr 1
9 50661-VIR-000 Rubber Step Fr R/L 2
10 50710-VIR-000 Holder L Step 1
11 50661-VIR-000 Rubber Step Rr. R/L 2
12 50713-VIR-000 Bar R Pillion Step 1
13 50714-VIR-000 Bar L Pillion Step 1
14 50711-VIR-000 Washer Pillion Step Rr. 2
15 50715-VIR-000 Holder Rear R Pillion Step 1
16 50716-VIR-000 Holder Rear L Pillion Step 1
17 50720-VIR-000 Sub. Assy. Fr. Pillion Step L 1
18 96000-08022-04 Bolt Flange M8x22 8
19 96100-0610-00 Sub Assy. Fr. Pillion Step L 1
20 50641-VIR-000 Holder Fr. Pillion Step R Assy. 1
Page 36
F.V2R – 19
Stand
1 50530-VIR-000 Bar Comp Side Stand 1
2 90107-VIR-000 Bolt Side Stand Pivot M10x35 1
3 94001-10000-00 Spring Side Stand 1
4 50543-VIR-000 Nut Hex., M10 1
5 50531-VIR-000 Side Stand Assy. 1
Page 37
F.V2R – 20
Swing Arm /
Chain Case
1 21001-V2R-000 Case Drive Chain 1
2 40530-VIR-000 Chain Drive 1 Not Used
40530-V2R-000 Chain Drive *428 - 130* 1
3 40543-VIR-000 Adjuster Chain 2
4 40546-VIR-000 Cap Rr. Fork End 2
5 21002-V2R-000 Slider Chain 1
6 21003-V2R-000 Swing Arm Set Rr. 1
7 21004-V2R-000 Bolt Axle Swing Arm Pivot 1
8 94001-08000-00 Nut Hex 8 mm 2
9 90301-14000-00 Nut U M14 1
10 43431-VIR-000 Rubber Rr. Brake Stopper 1
11 90410-08000-00 Washer Plate 8 mm 2
12 96000-06012-00 Bolt Flange 6x12 1
13 90410-06000-04 Washer Plate 6 mm 5
14 96406-VIR-000 Plate Adjuster 2
15 94111-08000-00 Washer Spring 8 mm 2
16 40544-VIR-000 Adjuster Chain Set 2
17 40547-VIR-000 Bush Set Swing Arm 1
18 96000-06012-04 Bolt Flange 6x12 3
Page 38
F.V2R – 21
Rear Cushion
1 52400-VIR-000 Cushion Assy Rr 1
2 96000-10045-00 Bolt Flange 10x45 2
3 90301-10000-00 Nut U 10mm 1
Page 39
F.V2R – 22
Rear Fender
1 22001-V2R-000 Bulb Number Plate 12V/5W 1 21 96000-06016-00 Bolt Flange M6x16 2
2 22002-V2R-000 Light License Assy. 1 22 94050-05000-03 Nut Flange M6 2
3 22003-V2R-000 Cover Light License 1
4 90410-06000-00 Washer Plate 6mm 2
5 94050-05000-00 Nut Flange M5 1
6 22005-V2R-000 Reflector 1
7 22006-V2R-000 Bracket Rear Fender 1
8 22007-V2R-000 Rear Fender 1
9 22008-V2R-000 Rear Lower Fender Inner 1
10 22009-V2R-000 Cover Rear Under 1
11 22010-V2R-000 Cover Battery 1
12 96000-06012-00 Bolt FlangeM6x12 1
13 90677-05000-00 Nut Clip M5 5
15 96000-08016-00 Bolt Flange M8x16 3
16 90101-03012-00 Screw Tapping M3x12 2
17 54109-V2R-000 Rubber Light 2
18 90101-04210-00 Screw Tapping M4,2x10 2
19 22011-V2R-000 Cover Seat Lock 1
Page 40
F.V2R – 23
Caution
1 77314-VIR-000 Stripe Drive Chain 1
2 77315-VIR-000 Stripe Starting Produce 1
3 77316-VIR-000 Stripe Information 1
4 77317-VIR-000 Stripe Caution 1
5 87308-KRN-000 Label *Triangle Mptorindo* 1
Page 41
F.V2R – 24
Taillight
1 24001-V2R-000 Taillight Assy. 1
2 24002-V2R-000 Taillight Lens 1
3 24003-V2R-000 Led Comp. 1
4 24004-V2R-000 Socket Lamp. Taillight 1
5 24005-V2R-000 Bulb 12V-21/5W 1
6 90101-03010-00 Screw Tapping M3x10 3
7 90101-04010-00 Screw Tapping M4x10 2
8 90101-04813-00 Screw Tapping M4,8x13 4
9 24006-V2R-000 Rr. Winker R. Assy. 1
10 24007-V2R-000 Rr. Winker L. Assy. 1
11 24008-V2R-000 Led Cable Comp. R 1
12 24009-V2R-000 Led Cable Comp. L 1
13 30007-TVX-000 Led 20
14 24010-V2R-000 Rear Base R/L Winker 2
15 94050-10000-00 Nut Flange M10
Page 42
F.V2R – 25
Battery
1 31500-VIR-000 Battery 6Ah12V 1
2 35851-VIX-000 Cushion Magnetic Switch
3 35255-VIX-000 Switch Assy Starter Magnetic 1
4 32601-VIX-000 Cable Battery Ground 1
5 35850-VIX-000 Switch Magnetic Comp. 1
6 94001-06000-00 Nut Hex., M6 4
7 94101-06000-00 Washer Plain 6 mm 2
8 94111-06000-00 Washer Spring 6 mm 4
Page 43
F.V2R – 26
Wireharness
1 32100-V2R-000 Wireharnnes Assy. 1 Not Used
1a 32101-V2R-000 Wireharnnes Assy. New 1
2 30510-VIR-200 Coil Assy., Ignition 1
3 30500-VIX-000 Coil Comp. Ignition 1
4 30700-VIX-000 Cap Assy., Noise Suppressor 1
5 93500-05020-00 Screw Pan, 5x20 1
6 30410-V2R-200 CDI Unit Assy 1
7 30410-V2R-000 C.D.I. Unit 1
8 30401-VIX-000 Cushion, C.D.I. Unit 1
9 31600-VIX-200 Rectifier Assy., Regulator 1
10 38300-V2R-000 Relay Assy., Winker 1
11 38301-V2R-000 Relay Comp., Winker 1
12 38306-VIX-000 Suspension, Winker Relay 1
13 38110-VIR-000 Horn Comp. 1
14 96000-06016-00 Bolt Flange M6x16 3
15 98200-VIR-000 Fuse B (15A) 1
16 22211-V2R-000 Cable Ties 1
Page 44
F.V2R – 27
Frame Body
1 50354-VIR-000 Bracket Engine 1
2 50100-V2R-000 Body Comp. Frame 1
3 94101-08000-00 Washer Plain 8 mm 2
4 94111-08000-00 Washer Spring 8 mm 2
5 96000-08040-00 Bolt Flange M8x40 4
6 50533-V2R-000 Rubber Knop Frame 2
7 96000-08095-00 Bolt Flange M8x95 2
8 96100-06012-00 Bolt Hex., M6x12 2 Not Used
9 94001-08000-00 Nut Hex., M8 2
10 90301-08000-00 Nut U M8 2
11 96000-10120-00 Bolt Flange 10x120 2
12 50353-V2R-000 Bracket Engine Mounting 1
13 50356-V2R-000 Rubber Frame Stasioner 1
14 94111-10000-00 Washer Spring 10 mm 2
15 90410-10000-00 Washer Plate 10 mm 2
16 50357-V2R-000 Stay Shroud 1
17 94001-10000-00 Nut Hex., M10 2
18 96000-06012-00 Bolt Flange M6x12 2
Page 45
F.V2R – 28
Tool Kit
1 89100-PRT-000 Tools Set 1
2 89102-PRT-000 Shaft, Screw Driver 1
3 89103-PRT-000 Grip 1
4 89211-PRT-000 Spanner, 08x10 1
5 89212-PRT-000 Spanner, 12x14 1
6 89213-PRT-000 Pliers, 135 1
7 89216-PRT-000 Wrench, Spark Plug 1
8 89219-PRT-000 Bag, Tool, 160mm 1
Page 46
F.V2R – 29
Stripe
1 29001-V2R-000-12 Stripe Set * Hitam-Merah* 1 Not Used 9 29009-V2R-000-2 Stripe Shroud Trun L* Merah* 1
29001-V2R-000-16 Stripe Set *Hitam-Putih* 1 Not Used 29009-V2R-000-4 Stripe Shroud Trun L*Hijau* 1
29001-V2R-000-14 Stripe Set *Hitam-Hijau* 1 Not Used 10 29010-V2R-000-6 Stripe Shroud Middle R* Putih* 1
1a 39001-V2R-000-12 Stripe Set * Hitam-Merah* 1 11 29011-V2R-000-6 Stripe Shroud Middle L* Putih* 1
39001-V2R-000-16 Stripe Set *Hitam-Putih* 1 12 29012-V2R-000-61 Stripe Shroud Lower R* Putih-Hitam* 1 Not Used
39001-V2R-000-14 Stripe Set *Hitam-Hijau* 1 29012-V2R-000-21 Stripe Shroud Lower R*Merah-Hitam* 1 Not Used
2 29002-V2R-000-61 Stripe Body R/L "R 200'* Putih-Hitam* 2 Not Used 12a 32014-V2R-000-61 Stripe Shroud Lower R* Putih-Hitam* 1
29002-V2R-000-26 Stripe Body R/L"R 200*Merah-Putih* 2 Not Used 32014-V2R-000-21 Stripe Shroud Lower R*Merah-Hitam* 1
2a 32013-V2R-000-1 Stripe Body R/L"R 200*Hitam* 2 13 29013-V2R-000-61 Stripe Shroud Lower L* Putih-Hitam* 1 Not Used
32013-V2R-000-2 Stripe Body R/L"R 200*Merah* 2 29013-V2R-000-21 Stripe Shroud Lower L*Merah-Hitam* 1 Not Used
3 29003-V2R-000-26 Stripe Fuel Tank Lower R.* Merah-Putih* 1 13a 39013-V2R-000-61 Stripe Shroud Lower L* Putih-Hitam* 1
29003-V2R-000-46 Stripe Fuel Tank Lower R.*Hijau-Putih* 1 39013-V2R-000-21 Stripe Shroud Lower L*Merah-Hitam* 1
4 29004-V2R-000-26 Stripe Fuel Tank Lower L.* Merah-Putih* 1 14 29014-V2R-000-61 Stripe Fuel Tank Upper R*Putih-Hitam* 1
29004-V2R-000-46 Stripe Fuel Tank Lower L.*Hijau-Putih* 1 15 29015-V2R-000-61 Stripe Fuel Tank Upper L*Putih-Hitam* 1
5 29005-V2R-000 Emblem R *VIAR* 1 16 29016-V2R-000 Emblem L *VIAR* 1
6 29006-V2R-000-61 Stripe Shroud Upper R* Putih-Hitam* 1
7 29007-V2R-000-61 Stripe Shroud Upper L* Putih-Hitam* 1
8 29008-V2R-000-2 Stripe Shroud Trun R* Merah* 1
29008-V2R-000-4 Stripe Shroud Trun R*Hijau* 1
Page 47
F.V2R – 29a
New Stripe
2014
1 29101-V2R-000-21 Stripe Set * Merah-Hitam* 1 12 29108-V2R-000 Stripe Text "VSR" R 1
29101-V2R-000-41 Stripe Set *Hijau-Hitam* 1 13 29109-V2R-000 Stripe Text "VSR" L 1
2 29102-V2R-000-26 Stripe Body R/L"R 200*Merah-Putih* 2 14 29114-V2R-000-21 Stripe Fuel Tank Upper R*Merah-Hitam* 1
3 29106-V2R-000-21 Stripe Shroud R* Merah-Hitam* 1 29114-V2R-000-41 Stripe Fuel Tank Upper R*Hijau-Hitam* 1
29106-V2R-000-41 Stripe Shroud R* Hijau-Hitam* 1 15 29115-V2R-000-21 Stripe Fuel Tank Upper L*Merah-Hitam* 1
4 29107-V2R-000-21 Stripe Shroud L* Merah-Hitam* 1 29115-V2R-000-41 Stripe Fuel Tank Upper L*Hijau-Hitam* 2
29107-V2R-000-41 Stripe Shroud L* Hijau-Hitam* 1 16 77312-V2R-000 Stripe Text "VIAR" 2
5 29105-V2R-000 Stripe Text Fuel Tank *VIAR* 2
6 29012-V2R-000-2 Stripe R Bottom Cowl "Merah" 1
29012-V2R-000-4 Stripe R Bottom Cowl "Hijau" 1
7 29013-V2R-000-2 Stripe L Bottom Cowl "Merah" 1
29013-V2R-000-4 Stripe L Bottom Cowl "Hijau" 1
8 29116-V2R-000-12 Stripe R Front Cowl "Hitam-Merah" 1
29116-V2R-000-14 Stripe R Front Cowl "Hitam-Hijau" 1
9 29117-V2R-000-12 Stripe LFront Cowl "Hitam-Merah" 1
29117-V2R-000-14 Stripe L Front Cowl "Hitam-Hijau" 1
10 29110-V2R-000-21 Stripe Shroud Middle R* Merah-Hitam* 1
29110-V2R-000-41 Stripe Shroud Middle R* Hijau-Hitam* 1
11 29111-V2R-000-21 Stripe Shroud Middle L* Merah-Hitam* 1
29111-V2R-000-41 Stripe Shroud Middle L* Hijau-Hitam* 1
Page 47a
F.V2R – 30
Oil Cooler
1 17000-KRY-000 Cooler Oil, Assy 1
2 17100-KRY-000 Cover Cooler 1
3 17110-KRY-000 Cooler Spacer 1
5 17121-KRY-000 Collar Oil Cooler 2
6 94001-03000-00 Nut, Hex 3mm 4
7 90410-03000-00 Washer, Plate 3mm 4
8 94111-03000-00 Washer, Spring 3mm 4
9 17125-V2R-200 Hose Comp, Oil Cooler Long 550 mm 1
10 17135-V2R-000 Hose Comp, Oil Cooler Short 240 mm 1
11 17130-KRY-000 Bolt Oil Cooler, Hose Union M8x25 4
12 90440-08000-02 Washer Sealing Hose Oil Cooler 8
13 96000-06025-00 Bolt Flange M6x25 2
Page 48
F.V2R – 31
Upper Cowl
1 31001-V2R-000 Cowl Front Upper 1
2 31002-V2R-000 Screen Wind 1
3 31003-V2R-000 Cowl R. Fr. 1
4 31004-V2R-000 Cowl L. Fr. 1
5 31005-V2R-000 Cowl R. Side Inner 1
6 31006-V2R-000 Cowl L. Side Inner 1
7 31007-V2R-000 Cowl Fr. Inner 1
8 31008-V2R-000 Lid R. Tank 1
9 31009-V2R-000 Lid L. Tank 1
10 31010-V2R-000 Stay R. Fr. Inner 1
11 31011-V2R-000 Stay L. Fr. Inner 1
12 90101-04213-00 Screw Tapping M4,2x13 10
13 90677-05000-00 Nut Clip M5 2
14 31012-V2R-000 Spin Snap 6
15 31013-V2R-000 Clip Snap 4
17 31014-V2R-000 Rubber Cover Speedo 3
18 90410-06000-00 Washer Plate 6 mm 3
Page 49
F.V2R – 32
Shroud and
Cowl Cover
1 32001-V2R-000-BC Cowl R Middle*Hitam* 1 32010-V2R-000-GN Acsesoris Shourd L *Hijau* 1
2 32002-V2R-000-BC Cowl L Middle*Hitam* 1 32010-V2R-000-BC Acsesoris Shourd L *Hitam* 1
3 32003-V2R-000-RD Shroud R *Merah* 1 11 90101-04213-00 Screw Tapping M4,2x13 30
32003-V2R-000-WH Shroud R *Putih* 1 12 96000-06016-00 Bolt Flange M6x16 2
32003-V2R-000-GN Shroud R *Hijau* 1 13 90410-06000-01 Washer Plate 6 mm 10
32003-V2R-000-BC Shroud R *Hitam* 1 14 80120-VIR-000 Rubber Washer 6
4 32004-V2R-000-RD Shroud L *Merah* 1 15 31013-V2R-000 Clip Snap 6
32004-V2R-000-WH Shroud L *Putih* 1 16 32011-V2R-000 Bracket Winker R 1
32004-V2R-000-GN Shroud L *Hijau* 1 17 32012-V2R-000 Bracket Winker L 1
32004-V2R-000-BC Shroud L *Hitam* 1 18 90677-05000-00 Nut Clip M5 1
5 32005-V2R-000-BC Shroud Fr. Inner. R*Hitam* 1 19 93501-05016-01 Screw Truss Head M5x16 1
6 32006-V2R-000-BC Shroud Fr. Inner L *Hitam* 1 20 93501-06016-01 Screw Truss Head M6x16 8
7 32007-V2R-000-BC Shroud Rr. Inner. R*Hitam* 1 21 90101-04210-00 Screw Tapping M4,2x10 2
8 32008-V2R-000-BC Shroud Rr. Inner. L*Hitam* 1
9 32009-V2R-000-RD Acsesoris Shourd R *Merah* 1
32009-V2R-000-WH Acsesoris Shourd R *Putih* 1
32009-V2R-000-GN Acsesoris Shourd R *Hijau* 1
32009-V2R-000-BC Acsesoris Shourd R *Hitam* 1
10 32010-V2R-000-RD Acsesoris Shourd L *Merah* 1
32010-V2R-000-WH Acsesoris Shourd L *Putih* 1
Page 50

SSX-200 Part Catalog PDF

Diunggah oleh

Informasi Dokumen

Deskripsi Asli:

Judul Asli

Hak Cipta

Format Tersedia

Bagikan dokumen Ini

Bagikan atau Tanam Dokumen

Opsi Berbagi

Apakah menurut Anda dokumen ini bermanfaat?

Apakah konten ini tidak pantas?

Hak Cipta:

Format Tersedia

SSX-200 Part Catalog PDF

Diunggah oleh

Hak Cipta:

Format Tersedia

Petunjuk Pemakaian Catalog

EV - 4 Cylinder EV - 5 Right Crank Case Cover EV - 6 Clutch

EV - 7 Oil Pump EV - 8 Left Crank Case Cover EV - 9 Generator

EV -16 Starting Motor EV - 17 Carburetor EV - 18 Balance Shaft

F.V2R – 5 Handle Pipe /

F.V2R – 7 Front Fender F.V2R – 8 Front Fork F.V2R – 9 Front Wheel

F.V2R – 13 Body Cover F.V2R – 14 Double Seat F.V2R – 15 Air Cleaner

F.V2R – 16 Exhaust Muffler F.V2R – 17 Pedal F.V2R – 18 Step

F.V2R – 22 Rear Fender F.V2R – 23 Caution F.V2R – 24 Taillight

F.V2R – 25 Battery F.V2R – 26 Wire Harness F.V2R – 27 Frame Body

F.V2R – 31 Upper Cowl F.V2R – 32 Shroud and Cowl Cover

Anda mungkin juga menyukai
