LOTO Procedure

&
Tagging Procedure for
Inserting and Removing Blind
TYPE BLIND
ELECTRICAL ISOLATION
Taging :

1. Operation Yellow Tag

2. Mechanic : Blue Tag
3. Instrument : Turquoise Tag
Electrical : Pink Tag.
WRONG BLIND INSERTING
1. PURPOSE

Untuk membuat standar yang sistematik dari Lock Out dan Tag Out (LOTO)
yang melibatkan sumber energy bahaya, seperti suhu, tekanan, zat berbahaya,
dll., sebelum bekerja, saat bekerja, dan setelah selesai bekerja dengan
peralatan terkait dan sumber bahaya lain. Memastikan pekerjaan aman, tidak
menyebabkan accident, incident, dan nearmiss, termasuk cedera, kehilangan
properti, dan kerusakan lingkungan ketika bekerja di fasilitas CAP.

2. SCOPE

LOTO digunakan untuk semua pekerjaan di area PT. Chandra Asri
Petrochemical, Tbk. oleh pekerja yang dilibatkan dalam pekerjaan dengan
sumber energi dan/atau melepas alat atau pipa yang berbahaya di proses
produksi atau dalam sumber energi yang berbahaya, seperti tekanan, suhu,
zat berbahaya, dll
2. SCOPE CONT.

Setiap orang yang dilibatkan harus memenuhi standar, yang terdiri dari
karyawan CAP, kontraktor, dan kontraktor temporary dan individu lain yang
dapat dicederai oleh pekerjaan, kecuali ada kontrol khusus yang mempunyai
instruksi kerja dan isi yang sesuai prosedur operasi standar untuk isolasi
sumber listrik dan/atau Line Break.

Ketika proyek baru atau harus memodifikasi sistem lebih lanjut, perhatikan
bahwa sistem dapat diisolasi dengan aman, dan juga memperhatikan
pemasangan Valve, Drain-point-Vent, dan sebagainya.
 LOTO TRACKING CARD AND LOTO TAGS
1.LOTO Tracking Card or Drawing shall be supplied by Area Authority.
All parties shall use the same LOTO Tracking Card or Drawing as used
by Area Authority.

2.There are four colors of LOTO Tagging Cards, Yellow for Area
Authority, Dark Blue for Work Execution Authority, Pink for Electrical
Section and Turquoise for Instrument Section.
ABBREVATION
CAP : PT. Chandra Asri Petrochemical, Tbk.
CCR : Central Control Room
CSS : Control Switch Station
COS : Control Operating Switch
LOP : Local Operation Panel
HSE : Health Safety Environment
LOTO : Lock Out Tag Out
MCC : Motor Control Center
MOV : Motor Operated Valve
P&ID : Piping and Instrumentation Diagram
PTW : Permit To Work
 General LOTO Step of Work
* AA menyiapkan paket isolasi untuk kegiatan yang terdiri dari prosedur
isolasi, pembaharuan P&ID, LOTO Tracking Card dan proses persetujuan.

* AA harus membuat rencana isolasi dan identifikasi lokasi untuk mengunci di

P&ID dan form LOTO Tracking Card.

* Field Operator AA harus menjadi yang pertama untuk mengetahui bahwa

inlet dan outlet valve isolasi telah pada kondisi yang diinginkan (tutup/buka)
dan di tag. Semua valve yang dikunci dan tag harus dicatat di LOTO Tracking
Card dan P&ID terbaru. Pihak lain juga akan menggunakan Tracking Card
atau P&ID yang digunakan oleh Area Authority.

* Kunci milik AA harus ditempatkan di CCR/PCR.

* Field Operator AA melepaskan tekanan dan residu chemical dan kemudian

verifikasi bahwa sistem isolasi telah aman dengan memilih metode tes
sekurangnya dua cara seperti pembacaan pressure gauge, membuka drain,
knocking sound, check temperature, check gas, test run, machinery, dll.
* WEA harus lock dan tag valve yang sama dan mencatatnya sebelum
memulai pekerjaan ( merujuk ke Standard OSHA 29 CFR 1910.147)

Jika power perlu untuk diisolasi, pada MCC wajib dikunci dan ditag untuk
semua voltase. Perhatikan hal berikut:
* Untuk isolasi elektrikal kurang dari 380 kV dapat dilakukan oleh
AA dan untuk isolasi elektrik lebih dari 380 kV harus dilakukan oleh
Electrical Section dan AA.
* Electrical Section wajib rack out di MCC kemudian lock dan tag
pada switch gear di switch house dan juga mencatat semua lock dan
tag yang digunakan.
* Isolasi elektrik pada tegangan 6 kV atau diatasnya, dilarang
menggunakan cincin dan jam tangan dari metal untuk mencegah
sengatan listrik
* Di CSS/LOP/COS, AA dan Electrical wajib meletakkan tag dan
lock (tergantung dari fasilitasnya). Jika tidak ada fasilitas untuk
lock, mereka tidak perlu lock dan hanya tag (mandatory).
*Jika sebuah instrumentasi dilibatkan, Instrument Section wajib lock dan tag
energi yang terisolasi, seperti udara atau suplai listrik ke instrumen dan
mencatatnya.

*Jika dibutuhkan untuk mengetes peralatan atau solo run tes, seluruh
aktifitas harus dicatat dan meminta persetujuan kepada AA sebelum
melalukannya.

*Ketika pekerjaan telah selesai, Work Execution Authority harus melepaskan

semua lock dan tag yang diletakkan olehnya, catat dan tanda tangan pada
LOTO Tracking Card removed column dan kembalikan Master Work Permit.

*Sebelum commissioning, AA harus melepaskan semua lock dan tag dan

menandatangani LOTO removed column dari LOTO Tracking Card.
 Tagging Procedure for Inserting and Removing
Blind
• 1. PURPOSE
• To provide a systematic work procedure for tagging,
inserting and removal of blind, especially during
TAM/SDM, when thousands of blinds will be inserted
and removed, thus, enhancing safety, job planning and
productivity in CA.

• 2. SCOPE
• This procedure shall be used whenever blind has to be
installed for positive isolation before work is to be
carried out safely and for removing blind before a
system is commissioned. This procedure shall be
practiced in all Red Areas of CA.
• 4. DEFINITION
Blinds shall include:
• Spectacle blind that is permanently installed in a pair of
flanges.
• Round blind cut from steel plate with a handle for
positive isolation of a line or equipment.
• End blank to blank off a disconnected line.
• End blank to blank off a valve when a R/V or equipment
is removed.
• 90 degree elbowed blanks to blank off both flare and
product sides after a R/V or equipment is removed.
• Slide plates for isolation of furnace ducting.
• Others as specified by Area Authority or Work
Execution Authority.
 5. ACTIVITIES
TAGGING PEROCEDURE FOR INSERTING OR REMOVE BLINDS
• For reference:
• See “Cards for Inserting and Removing Blinds”.
Appendix #1
• See “Tagging Procedure Illustration of Hanging Tags and Blind Work”.
Appendix #2
• See “LOTO for Record and Control of Blind Work”.
Appendix #3
• See “Example of Drawing for Isolation and Blind Work”.
Appendix #4
• The above references explain clearly the tagging procedure for inserting or removing
blinds. This practice is part of the Lock Out and Tags Out (LOTO) system and it will
enhance the following safety management on blinds:
• Work Execution Authority has been shown by Area Authority where he shall insert the
blinds.
• With the tags in place he will not forget where are the flanges he needs to insert blinds.
• Work Execution will be able to show the fitters where to insert the blinds.
• Fitters will not make mistake because he has cards which bears the same number as the
ones hung on the flanges.
• Fitter will inform Work Execution Authority that had inserted the blind by returning 2
cards.
• Work Execution Authority will check that the blinds are inserted properly when he
retrieves a card from the flanges and return all cards to Area Authority.
• The procedures are the same for removing of blinds.
• All blinds inserted and removed shall be recorded in “LOTO for Record and Control of
Blind Work” with cross-reference to the Drawing for Blind Work.
 Appendix #1
CARDS FOR INSERTING AND REMOVING BLINDS

CARD NO. IN 00001 CARD NO. IN 00001

TAG NO._______________________ TAG NO._______________________

BLIND NO._____________________ BLIND NO._____________________

INSERTED CHECKED BY WORK REMOVED CHECKED BY WORK
EXECUTION AUTHORITY: EXECUTION AUTHORITY:

NAME_________________________ NAME_________________________

CARD NO. IN 00001 CARD NO. IN 00001

TAG NO._______________________ TAG NO._______________________

BLIND NO. _____________________ BLIND NO. _____________________

INSERTED BY FITTER. REMOVED BY FITTER.

CARD NO. IN 00001 CARD NO. IN 00001

TAG NO._______________________ TAG NO._______________________

BLIND NO. _____________________ BLIND NO. _____________________

FLANGES SHOWN TO FITTERS. BLIND SHOWN TO FITTERS.

CARD NO. IN 00001

CARD NO. IN 00001
TAG NO._______________________
TAG NO._______________________
BLIND NO._____________________
BLIND NO._____________________
FITTERS INSTRUCTED TO
FITTERS INSTRUCTED TO INSERT
REMOVE BLIND.
BLIND.
TEST RUN AND TROUBLESHOOTING :

This is allowed under the following conditions :

WEA request the test run to AA.

1. WEA remove the Lock and Tag.

2. AA removes his Lock and Tag from the equipment. Only
equipment related to the test is de isolated.
3. WEA proceeds with the equipment test.
4. Once the test is completed, WEA inform the AA.
5. AA will then ensures the equipment isolation return to previous
condition and secures the group lock keys.
 Appendix #4
DRAWING FOR ISOLATION AND BLIND WORK: NO: 1234/06

TO FUEL GAS CARD NO.IN 00002

INSERTED DATE:________
SIGN:______________________

CARD NO. OUT 00002

REMOVED DATE:_________
CARD NO.IN 00004
INSERTED DATE:________
SIGN:______________________
.. SIGN: ______________________

CARD NO. OUT 00004

REMOVED DATE:_________
SIGN: ______________________ C 5001

CARD NO.IN 00003

INSERTED DATE:________
CARD NO.IN 00001
SIGN:______________________
INSERTED DATE:________
SIGN:______________________
.. CARD NO. OUT 00003
REMOVED DATE:_________
CARD NO. OUT 00001
SIGN: ______________________
REMOVED DATE:_________
SIGN: ______________________
CO

TO E 5003

TO SOUR WATER
STRAINER OPEN

G 5001
 TANK ISOLATION (SOUR SERVICE)

TO FLARE
HEADER

BLANKET GAS LO
LO

BALANCE LINE
OIL OUTLET

OIL INLET
WATER OUTLET
Breakout
Spool

NC NC

NC
CLOSED DRAIN
HEADER
Normal Operation

TO FLARE
HEADER

WARNING. The ‘Blind’ on the tank vent line to Flare can only be
BLANKET GAS LC swung if the station / facility is Shutdown or an isolation valve
LC is provided on the line upstream of the spade location.

BALANCE LINE
OIL OUTLET
LC
LC
Flange
Blinded

LC LC
OIL INLET
WATER OUTLET
LO
NOTE. The Bleed Valve LC
will be locked open to
relieve any pressure build Breakout
up to the closed drains. Spool LC
Provision should be made
Removed
to provide a means of LC LC
monitoring the bleed line
from the ‘double block
and bleed’

LO
SPADE CLOSED DRAIN
HEADER
Isolated
 VESSEL (SOUR SERVICES)

To Vent / Flare

Blowdown
to Flare

LO LO
Gas
Outlet

Inlet
H
LG LG LA
NC
L

NC

Closed Drains
NC NC
NC NC NC Liquid
Outlet

NC

NC

To Closed Drains
Header

Normal Operation

To Vent / Flare

WARNING. The ‘Blinds’ on the

Pressure Safety Relief and Blowdown
lines can only be swung if the vent
and flare systems are shutdown or Blowdown
isolation valves are provided to Flare
upstream of the Relief and Blowdown
valves. LC LC
Gas
Outlet

LC LC
Inlet
H
LG LG LA
LO
L

LO

Closed Drains
NOTE. The Bleed Valve NC NC
will be locked open to
relieve any pressure build NC NC NC Liquid
up to the closed drains. Outlet
Provision should be made
to provide a means of
monitoring the bleed line
from the ‘double block NC
and bleed’
NC

SPADE To Closed Drains

Header

Isolation
 CENTRIFUGAL PUMP

Casing Vent to
Safe Area
Pump Discharge

NC
Pump Suction

PG
PG

Vent/Local/
Atmos Flare

Motor

Seal Drain Pot

NC NC

NC Drain/Local Drain
Collection Tank

To Closed Drains
Header

Normal Operation

CENTRIFUGAL PUMP
Casing Vent to
Safe Area

Pump Discharge

LC
NO
Pump Suction

LC

PG
PG Electric motor
NC
isolated at the
Vent/Local/
main breaker Atmos Flare

Motor

Seal Drain Pot

NC NC

NC
Drain/Local Drain
Collection Tank

NC
To Closed Drains
Header

Isolation
